• Dual-halogen composite headlamps
  • Direct light to help improve down-the-road visibility during nighttime driving
• Flasher
  • Heavy-duty, LED
• Solar-Ray^® light-tinted glass
  • Used on windshield and front doors to help minimize interior heat buildup and direct glare caused by the suns rays
• Front license plate kit
• Front intermittent wipers
  • Variable-speed
  • Washers to keep the windshield clean
• Paint, solid
• Summit White
• Velvac outside wide-stance sail panel mounted mirrors
  • Velvac convex driver and passenger outside mirrors, sail panel mounted with arms that provide a wide stance
  • 63.3 square-inch flat glass positioned over a 30.1 square-inch convex glass mounted in a common head
  • Can be utilized with bodies up to 96-inches in width
  • Shipped loose in vehicle for dealer or upfitter installation
• Chrome grille
  • Makes a bold statement with this available Chrome grille
  • May require additional optional equipment
• 16" LT225/75R16E all-season blackwall spare tire
  • May require additional optional equipment
• Dual Rear Wheels
• 16" LT225/75R16E all-season blackwall front tires
• 16" LT225/75R16E all-season blackwall rear tires
• 16" x 6.5" steel wheels
  • Gray center caps
• Tire valve stems, long, brass, for inside dual rear wheels Brass metal 3-3/8" long valve stems on the inner wheels of dual rear wheel axles for easy air inflation.
• Chrome front bumper
• Tire valve stem caps, air thru Air through valve caps on the tire air valves

• Interior lighting
  • Dome light
  • Door handle activated switches
• Assist handles
  • Front A-pillar mounted for Driver and Passenger
• Cloth headliner
• Driver and front passenger high-back bucket seats
  • With head restraints and vinyl or cloth trim
• Inside rearview auto-dimming mirror
  • Automatically dims the inside rearview mirror when it senses bright light from behind
  • Includes rear view camera display
• Driver Information Center
  • Includes warning messages and vehicle information
  • Average vehicle speed and fuel economy
  • Fuel range
  • Trip odometer
  • Tire pressure and oil life
• Heater and defogger
  • Includes windshield and side window defoggers
• 120-volt power outlet
  • 3-prong auxiliary household-style outlet
  • Can be used to plug in electrical equipment, such as a cell phone or a portable device
• Air conditioning
  • Cools and dehumidifies the air inside the vehicle
  • Allows you to manually control temperature, fan speed and sources of airflow
• Warning tones
  • Headlamp on and key-in-ignition
• Medium Pewter, Custom Cloth seat trim
• Power door locks
  • Allows you to lock and unlock doors easily whether it's from the driver or passenger seat or from outside using the key fob
  • Lockout protection helps you avoid locking keys in the vehicle
• Cruise control
  • Maintains a selected speed while driving
  • Set and resume speed functions
  • May require additional optional equipment
• High idle switch
  • Customer manually activates the high idle switch by engaging cruise control (parking brake must be set)
  • Once high idle is active, the DIC will display "Fast Idle Active"
  • High idle can be deactivated by disengaging cruise control, releasing the parking brake or applying the service brake
  • May require additional optional equipment
• Outside temperature display
  • Located in the Driver Information Center
• Power windows
• Auxiliary rear heater provisions
  • May require additional optional equipment
• Console, deluxe with swing-out storage bin
  • Keeps valuables and small items secure
• Cloth front bucket seats
  • High back bucket seats
  • Each seat has its own armrest and head restraint
  • May require additional optional equipment

• Power steering
• Rear wheel drive
• Incomplete Vehicle Certification
  • May require additional optional equipment
• Standard body
• Suspension, front independent with coil springs and stabilizer bar
• 4-wheel antilock disc brakes
  • Help reduce wheel lockup and maintain steering control during hard braking on most slippery surfaces
  • May require additional optional equipment
• Aluminized stainless-steel muffler and tailpipe
• Ladder-type frame
  • High-strength steel
• 32 gallon (121.1 liters), fuel tank
  • Mid-frame location
• Rear hypoid drive axle with multi-leaf spring suspension
• 3.73 rear axle ratio
  • May require additional optional equipment
• Soft-mount body-mount "donuts" and bolts
  • Designed for mounting an upfit body to vehicle chassis
• Wiring junction block accessory equipment
  • 2-30 amp circuits
  • May require additional optional equipment
• Emission System, 10K-14K GVW
• Emissions, Federal requirements
• 220-amp alternator
  • May require additional optional equipment
• Automatic locking rear differential
  • When the differential senses a significant difference in wheel speed, it locks to turn both rear wheels in unison for added traction
  • The Eaton^® Locker senses a difference in wheel speed of approximately 100 rpm
• Fuel, additional 3-gallons 3 gallons of fuel in addition to normal assembly plant fill
• Heavy-duty 770 cold-cranking amps Isolated second heavy-duty battery
  • Battery, 770 cold-cranking amps primary
  • Isolated second heavy-duty 770 cold-cranking amps
  • Allows second battery to be used when the vehicle is not running without affecting ability to start the vehicle
  • May require additional optional equipment
• Stop/Turn Signal circuits
  • Body Control Module calibration that allows the stop and turn signals to be operated separately
• 12,300 lbs. GVWR
  • When properly equipped; includes weight of vehicle, passengers, cargo and equipment

• Work Van Preferred Equipment Group Includes standard equipment
• Driver Convenience Package
  • Tilt steering wheel
  • Cruise control
• Power Convenience Package
  • Power windows
  • Power door locks
• Chrome Appearance Package
  • Front and rear chrome bumpers
  • Chrome grille
• Ambulance Package
  • Available on 3500 139" and 159" wheelbases and 4500 159" wheelbase
  • 220-amp alternator
  • Dual batteries (770 cca primary and 770 cca isolated)
  • Heavy-duty locking rear differential
  • Cruise control
  • High-idle switch
  • Dual-note horn
  • Auxiliary rear heater provisions
  • Stop/Turn Signal circuits
  • Wiring junction block for accessory equipment
  • Chrome Appearance Package
  • Chrome front bumper
  • Chrome grille
  • May require additional optional equipment

• Fleet Processing Option

• Daytime Running Lamps

• Airbag deactivation switch, frontal passenger-side (Not available with (AJ3) frontal, driver-side only airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• 2 airbags
  • Frontal airbags for driver and front passenger¹
• Airbags, seat-mounted side-impact for driver and right-front passenger and roof-rail mounted head-curtain side-impact (Included with (C4M) 9900 lb. (4490 kg) GVWR. Available on (JFF) 10100 lb. (4581 kg) GVWR, (C7N) 12300 lb. (5579 kg) GVWR, and (C7I) 14200 lb. (6441 kg) GVWR. Not available with (B3D) School Bus Package, (ANC) Shuttle Bus Package, (YF1) RV Package, and (9T7) right-hand door delete. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Rear Vision Camera
  • When in Reverse, shows you an image of the area directly behind your vehicle¹
  • Can help you park and avoid vehicles and objects
  • You can also display an overlay of where your vehicle is heading
• OnStar Basics
  • Drive confidently with core OnStar services including¹
  • Remote commands
  • Built-in voice assistance
  • Real-time traffic and navigation
  • Automatic Crash Response
• Tire Pressure Monitoring System
  • Monitors the pressure in each tire and alerts you if there is a low-pressure condition in one or more of the tires¹
• OnStar, delete (Includes (R9L) Removes OnStar Basics (OnStar Fleet Basics for Fleet).)
• Rear Camera Mirror
  • Uses a camera to provide you with the option of using a wide and less obstructed view behind your vehicle while driving instead of a traditional rearview mirror¹
  • The feature also allows brightness, vertical tilt and zoom adjustments
• Dual-note horn
• Deleted OnStar Basics (OnStar Fleet Basics for Fleet)

• Hill Start Assist
  • When you are stopped on an incline, this feature keeps the brakes engaged for a split second as you transition from brake pedal to gas pedal
  • Automatically releases once you press down on the accelerator
  • Prevent vehicle roll-back while the driver moves his/her foot from the brake to the accelerator pedal

Ambulance Package

Power Convenience Package

Driver Convenience Package

• DriveType
• DriveType: Rear Wheel Drive
• Fuel Economy
• City: 0 MPG
• Hwy: 0 MPG
• Combined: 0 MPG
• Fuel System
• Fuel System: Electronic Fuel Injection
• Fuel Tank Capacity
• Fuel Tank Capacity: 32 gal
• Fuel Type
• Fuel Type: Gasoline Fuel
• Horse Power
• Horse Power: 401
• Rear Wheel
• Rear Wheel: Dual
• Trailering Capacity
• Trailering Capacity: 0
